Injector Dynamics is proud to release the highly awaited F750 Fuel Filter. The F750 is manufactured in house, to ensure it meets the standards set forth by existing Injector Dynamics products.
Available w/ Short Backorder Delay. Contact Sales Dept. for Latest ETA.
|Dimensions||12 × 7 × 4 in|
With 22 years of documented research and development in the forced induction field, AMS Performance has proven itself as the powerhouse in the automotive aftermarket. Our award winning performance systems are what all others are measured by.
More Boost & More Power Needs More Fuel!
The ID F750 is the first performance filter designed to meet strict OE filter requirements, namely Bosch’s specification for electronic fuel injectors. It is the result of substantial research invested in improving the service life of our injectors. In addition to improved filtering, the ID F750 offers numerous features designed to increase performance and function.
Nominal Flow Rate – 750 l/h @ 7.5 kPa (1.1psi) pressure drop. 1000 l/h at 13 kPa (1.9psi) pressure drop
Maximum Fuel Pressure – 10.0 Bar (145.0 psi)
Fuel Compatibility – Compatible with all known fuels
Fluid Connection – SAE -8 o-ring barb
Weight – 700g
Electronic fuel injectors are built to precise dimensions, measured in microns. The smallest of particles can increase wear, or even destroy a fuel injector.
Bosch provides a specification for protection of electronic fuel injectors, which is a minimum capture efficiency of 87% at 5 microns, and 100% capture efficiency at 35 microns. This means that the filter will capture at least 87% of all particles 5 microns and larger, and 100% of all particles 35 micron and larger.
The filter element in the ID F750 meets that specification, and does so without undue flow restriction.
